Bucket Elevators

With us it's a steep climb to the top

Belt and chain bucket elevators from AMF-Bruns

Belt and chain bucket elevators from AMF-Bruns stand for economical vertical conveying with maximum availability – even in continuous operation and under the most extreme conditions. This makes them a cost-effective, space-saving and product-protecting alternative to long, sloping or steeply inclined conveyor belts.

Right from the design phase, our engineers ensure that buckets, belts, chains and drives are precisely matched to your needs. Of course, this also applies to the individual adaptation to the technical and spatial conditions on site. In this way, our bucket elevators guarantee maximum efficiency and investment security right from the start.

Ein Teambild aus der Abteilung Gurt- und Kettenbecherwerke.
Do you have any questions?

We are happy to help you!

Here you will find the right contact person for your questions and your industry.

We will be happy to answer any questions you may have about our bucket elevators for the green technology, wood and sugar industries.

Simply send us an e-mail to: mail@amf-foerderanlagen.de or speak directly to our experts:

Green Technology
+49 (0) 4489 72-7534
malte.wittje@amf-bruns-engineering.de
Malte Wittje

Wood Industry
+49 (0) 4489 72-7220
christian.mueller@amf-bruns-engineering.de
Christian Müller

Sugar Industry
+49 (0) 4489 72-7225
dennis.vonhorn@amf-bruns.de
Dennis von Horn

Brochure: Bucket Elevators

Here you can download an overview of our bucket elevators including technical data and performance-related specifications.

Performance at the highest level

Belt bucket elevators from AMF-Bruns

Optimal for gentle, low-noise transport: The belt bucket elevators from AMF-Bruns are characterized by a high conveying capacity of up to 1,000 t/h. On vertical conveying distances of over 100 meters, they reliably move large quantities of material while maintaining the quality of your goods. On request, our bucket elevators can also be made dust-tight, pressure-shock-proof and gas-tight.

Thanks to their small footprint, our bucket elevators allow for optimal space utilization. Another advantage is the low maintenance requirement. Our chain bucket elevators are ideally suited for transporting hot goods up to 400 °C and are also designed for transporting heavy and abrasive materials.

Your options:

  • Design in accordance with Regulation (EC) No. 1935/2004 – food contact materials
  • EX-protected design according to Directive 2014/34/EU
  • With maintenance platforms
  • Material combinations adapted to the field of application (e.g. heat- or pH-resistant as well as wear-resistant)
  • Movable scoops to reduce material deposits
  • Cleaning flaps and inspection openings
  • Different seal variants
  • Different belt variants (e.g. steel cable belts, heat- and cold-resistant belts)
  • Different chain variants (e.g. plate chains, round link chains, central chains)

Product variations:

Reliable and powerful

Belt bucket elevators

Belt bucket elevators from AMF-Bruns are in demand for the vertical transport of bulk materials: For example, they are used for filling silos or transporting products to another working level. The belt bucket elevators (GBW) from AMF-Bruns are available in sizes 315 to 1,800. Depending on the size, up to 1,000 m3/h can be conveyed.

Quickly to the top

High-performance bucket elevators

Our high-performance bucket elevators are designed for high-speed operation with up to 1,200 m3/h mass flow.

Hot goods

Chain bucket elevators

When it comes to coarse and hot goods transport, our chain bucket elevators are the right choice.

Safe transport

Central chain bucket elevators

We have designed our central chain bucket elevators to optimally transport abrasive and demanding bulk materials.

Our special solutions

Special designs

Always the right system: slow-moving and center discharge chain bucket elevators are suitable for light and sensitive bulk materials. Gas-tight bucket elevators in tubular shaft design were specially developed for inert materials.

Gently from A to B

Bucket elevators: Areas of application

Our bucket elevators are used in a wide variety of industries. They are ideal for conveying bulk materials gently and safely from one production step to the next.

Typical conveyed products are:

  • Wood chips
  • Sawdust & pellets
  • Recycling material
  • Raw sugar, wet or crystallized sugar
  • Iron oxide
  • Fertilizer

Added value for our customers

Value Added Services (VAS) at AMF-Bruns

Uncomplicated cooperation, fast response times and a solution-oriented approach – all this distinguishes AMF-Bruns as a partner. For us, service means being there for our customers at all times. Because our personal ambition is to ensure the highest level of customer satisfaction. Value Added Services at AMF-Bruns can therefore easily be summed up in one word: Trust.

Quality management

Certified quality: At AMF-Bruns, high-performance products, maximum delivery reliability and maximum economic efficiency are the guiding principles for all manufacturing processes.

Service

Your personal contact person is available to you at all times. On-site visits are also important to us in order to precisely understand customer requirements.

Consulting & Planning

With sales planning in 3D as well as a 3D scan for recording the environment in your plant, AMF-Bruns creates the best conditions for successful projects.

Get your non-binding offer now.

A strong partner at your side: From planning and commissioning to quality management and subsequent maintenance, we are with you every step of the way.
